Tylogy® USB 3.2 WiFi 7 BE6500Mbps Tri-Band Wireless Network Adapter Dongle
- Built-in Realtek® RTL8912AU WiFi 7 chipset
- USB 3.2 connector (backwards compatible with USB 3.1 Gen 1 and USB 2.0)
- Tri-band support: 2.4GHz, 5GHz and 6GHz native frequencies
- Up to 6500Mbps of ultra high-speed last-gen wireless bandwidth
- Featuring a set of 2 external 5dBi high gain tri-band antennas
- Complies with IEEE 802.11 a/b/g/n/ac/ax/be standards
- Compatible with Windows® 11 (64bits, 23H2/SV3+)
Product Warranty
For more details regarding Tylogy products warranty, please check out our Warranty Policy page.
Product Safety
Starting December 13th, 2024, any product sold on the EU market must comply with the GPSR (Regulation EU 2023/988). As part of that directive, economic operators placing products on the EU market must disclose the manufacturer's name and address and nominate a local EU representative entrusted with tasks relating to the safety of the products.
Product Manufacturer:
HCX Technologies Limited
Unit B, 11/F, 23 Thomson Road
Wan Chai District
Hong Kong SAR China
EU Representative:
Firx SAS (dba. HCX Europe)
32 boulevard de Strasbourg
CS 30108, 75468 Paris CEDEX 10
France
Key Specifications
| WiFi Technology |
WiFi 7 |
|---|---|
| WiFi Specification |
BE6500 |
| Network Bandwidth |
5001Mbps to 10Gbps |
Technical Details
| Technical Specifications | ||
|---|---|---|
| Product | TYBE9830 | |
| Product Revision | rev 1.0 | |
| Interfaces | USB 3.2 | |
| Wireless Frequencies | 2.4GHz: 688Mbps / 5GHz: 2882Mbps / 6GHz: 2882Mbps | |
| Total Bandwidth Capacity | 6452Mbps (BE6500) | |
| Chipset | Realtek® RTL8912AU | |
| Antenna Gain | 2 x 5dBi tri-band antenna | |
| Power Requirements | 5W | |
| Dimensions | 85.7 x 46.7 x 10.0 mm | |
| Weight | 0.045 kg | |
| Compatibility | ||
| Operating System Support |
|
|
| IEEE Support | 802.11 a/b/g/n/ac/ax/be | |
| Additional Features |
|
|
| Additional Information | ||
| Regulatory Compliance | FCC Part 15 Class B, CE, RoHS | |
| Operating Environment | Temperature: 0 ℃ to 45 ℃ Relative Humidity: 10%-90% (non-condensing) |
|
| Storage Environment | Temperature: -20℃ to 75℃ Relative Humidity: 5%-95% (non-condensing) |
|
| MTBF | >50,000h @ 25°C | |
| Packaging | ||
| Contents |
|
|
| Dimensions | 150 x 110 x 20 mm | |
| Weight | 0.10 kg | |
