Tylogy® Nordis WiFi 7 BE3600 Dual-Band 3.6Gbps Mesh Router with 2.5Gbps WAN Ethernet, 4 x Gigabit LAN Ethernet

SKU: NDBE3600

Buy Now

Support & Downloads

3.6Gbps Dual-Band WiFi 7 (BE3600) connectivity for blazing-fast downloads and uploads, latency-free online gaming and fluent 4K/8K streaming
2.5G Ethernet WAN port and 4 x Gigabit Ethernet LAN ports for boosted multi-gigabit wired connections
Featuring 4 high-gain external antennas for maximized wireless coverage and less interference
EasyMesh^®native support eliminates WiFi dead zones by allowing seamless multi Router/AP integration for uninterrupted internet access on the move
Easily share files between devices by plugging an external drive into the embedded USB 3.1 (Gen 1) port
Multi-regional wireless channels support and compliance: EU/UK (ETSI), USA (FCC), Japan, South Korea and China

Product Warranty

For more details regarding Tylogy products warranty, please check out our Warranty Policy page.

Product Safety

Starting December 13th, 2024, any product sold on the EU market must comply with the GPSR (Regulation EU 2023/988). As part of that directive, economic operators placing products on the EU market must disclose the manufacturer's name and address and nominate a local EU representative entrusted with tasks relating to the safety of the products.

Product Manufacturer:

HCX Technologies Limited
Unit B, 11/F, 23 Thomson Road
Wan Chai District
Hong Kong SAR China

www.hcx.com.hk

EU Representative:

Firx SAS (dba. HCX Europe)
32 boulevard de Strasbourg
CS 30108, 75468 Paris CEDEX 10
France

www.firx.eu

Key Specifications

WiFi Technology	WiFi 7
WiFi Specification	BE3600
Network Bandwidth	2501Mbps to 5000Mbps
Network Interface	Ethernet (RJ45)

Technical Details

Technical Specifications
Product	NDBE3600
Product Revision	rev 1.0
CPU	Quad-Core Broadcom® BCM6764L 2.0GHz ARMv8 SoC
RAM	512MB
Flash Memory	256MB
Wireless Controller(s)	Broadcom® BCM6764L
Wired Controller(s)	Broadcom® BCM53134
WAN Port(s)	1 x 2.5Gbps (IEEE 802.3bz) Ethernet
LAN Port(s)	4 x Gigabit Ethernet
USB Port(s)	1 x USB 3.1 Gen 1
Wireless Frequencies	2.4GHz (2.400~2.484GHz) EHT40: 688.5Mbps 5GHz (5.150~5.825GHz) EHT160: 2882.5Mbps
Max. Channel Bandwidth	160 MHz (EHT160)
Wireless Encryption	WPA3-SAE, WPA2-PSK, WPA-Enterprise
Regional Wireless Channels	EU/UK (ETSI), USA (FCC), Japan, South Korea, China
Antenna Gain	2×2 2.4GHz 5dBi external 2×2 5GHz 5dBi external
IEEE Compliance	802.11 a/b/g/n/ac/ax/be (WiFi) 802.3u/ab/bz (WAN) 802.3u/ab (LAN)
WFA Compliance	WFA Wi-Fi® 7 R1 WFA EasyMesh®
Advanced Functionalities	WPS VPN support (PPTP, L2TPv2, GRE) VLAN configuration (4 VLANs, max. 1 per LAN port) DDoS Protection QoS (global or by VLAN with custom classification) DDNS USB file sharing (FTP, Samba, DLNA) Parental Control (custom global or per device URL whitelist/blacklist with scheduling)
Modulation Schemes	BPSK/QPSK OFDM(A): 16-QAM, 64-QAM, 256-QAM, 1024-QAM, 4096-QAM (4K-QAM) DBPSK/DQPSK/CCK DSSS
Meshing Technology	WFA EasyMesh®
Power Requirements	18W (12V/1.5A power supply)
Dimensions	240 x 170 x 56 mm (without antennas)
Weight	0.50 kg
Additional Information
Regulatory Compliance	FCC Part 15 Class B, CE, RoHS
Operating Environment	Temperature: 0 ℃ to 40 ℃ Relative Humidity: 10%-90% (non-condensing)
Storage Environment	Temperature: -20℃ to 70℃ Relative Humidity: 10%-90% (non-condensing)
MTBF	>50,000h @ 25°C
Packaging
Contents	1 x NDBE3600 WiFi 7 Dual-Band Router 1 x CAT6A 1.0m Ethernet Cable 1 x 12V/1.5A power brick 1 x Quick Start Guide
Dimensions	350 x 350 x 70 mm
Weight	0.65 kg
